| PERFORMANCE |
| Display Size |
23.8" |
| View Area |
527x296.5 mm |
| Panel |
In-Plane Switching |
| Backlight |
WLED |
| Aspect Ratio |
16:9 |
| Resolution |
1920x1080 |
| Pixel Pitch |
0.2745x0.2745 mm |
| Dot / Pixel Per Inch |
93 dpi |
| View Angle (H / V) |
178° / 178° |
| Response Time |
4ms GtG (Extreme mode) / 6ms GtG (Typical mode) |
| Color Support |
16.7 Million |
| Refresh Rate |
48Hz - 120Hz |
| Brightness |
250 cd/m² |
| Contrast Ratio |
1500:1 |
| Color Gamut |
99% sRGB, 99%BT.709 |
| Screen Surface Treatment |
Anti-glare |
| Curvature |
None |
| Camera |
None |
| Microphone |
None |
| Speakers |
2Wx2 |
| Power Consumption (Typical / Maximum) |
16W / 157W |
| Power Adapter |
Integrated |
| Touchscreen |
None |
| Smart System |
None |
| DESIGN |
| Stand |
Tilt, Swivel, Pivot, Height Adjust Stand |
| Case Color |
Eclipse Black |
| Side Bezel Width |
2 mm |
| Mounting |
Supports VESA mount 100 x 100 mm |
| ThinkCentre M Series Support |
Tiny Support |
| Pen |
None |
| Dimensions (WxDxH) |
- Lowest Position | 539.8 x 190.0 x 350.8 mm (21.25 x 7.48 x 13.81 inches)
- Highest Position | 539.8 x 190.0 x 505.8 mm (21.25 x 7.48 x 19.91 inches)
- Head Only | 539.8 x 45.3 x 314.8 mm (21.25 x 1.78 x 12.39 inches)
|
| Packaging Dimensions (WxDxH) |
730.0 x 112.0 x 420.0 mm (28.74 x 4.41 x 16.54 inches) |
| Weight |
- Monitor With Stand | 5.6 kg (12.4 lbs)
- Monitor Head Only | 3.5 kg (7.7 lbs)
|
| Packaging Weight |
8.0 kg (17.6 lbs) |
| CONNECTIVITY |
| USB Port |
1x USB-C® (USB 5Gbps, PD 3.0 100W, USB upstream), 3x USB-A (USB 5Gbps, USB downstream), 1x USB-C (USB 5Gbps, 15W PD, USB downstream) |
| Video Connector |
1x HDMI® 1.4, 1x DP 1.4 (HBR2), 1x DP 1.4 Out, 1x USB-C® (5Gbps, DP 1.4 Alt Mode HBR2) |
| Network Connectivity |
1x RJ45, Ethernet (10M/100M/1000M) |
| SERVICE |
| Base Warranty |
3-year |
| CERTIFICATIONS |
| Environmental Certification |
ENERGY STAR® Certified, TCO 10, TCO Edge 2.1, EPEAT™ Gold, EU Energy Efficiency Level (Level-D) |
| Ergonomic Certification |
Eyesafe® Display 2.0, TÜV Low Blue Light (Hardware solution), TÜV Rheinland® Eye Comfort (5 Stars) |
| Sync Technology |
None |
| Special Features |
- Lenovo® ThinkColour (Lenovo Accessories and Display Manager) Support Lenovo ThinkColour supports Windows® 10 & 11, Mac OS (functions vary across systems). Lenovo Accessories and Display Manager is formerly Lenovo Display Control Center.
- LDFM (Lenovo® Display Fleet Manager)
- Mirrored Power Button
- Natural Low Blue Light
- Smart Power
|
| SOFTWARE |
| Operating System |
Support Windows® 10, Windows 11 |
| ACCESSORIES |
| Video Cables |
DP cable, USB-C® to USB-C cable |
| MODEL INFORMATION |
| Model |
64B9GAT1TK |
| Machine Type |
64B9 |
| Region |
EMEA |
| EAN / UPC / JAN |
0198156726186 / 198156726186 / None |
| Announce Date |
2025-06-20 |
